Hinge Type Chip Conveyor


Hinge Type Chip Conveyor

Specifications

Type Conveyor Systems, Automatic
Certification CE Certified
Application Industrial
Weight 100-1000kg
Voltage 220V
Power 1-3kw
Warranty 1 Year
 Driven Type Electric

Additional Information

Min. Order Quantity 01 Piece(s)
Payment Terms L/C, T/T
Delivery Time 3 to 4 Weeks
Packaging Details Wood packing

We offer Hinge Type Chip Conveyor System that is enough capable to handle both ferrous and non-ferrous materials. Manufacturer and Supplier of from Tamil Nadu, India. Our Conveyor Systems are configured with the components such as feeders, hoppers, etc. to provide a complete material handling system. Depending on the types, we proffer them out in several specifications and grades. Get in touch with us for acquiring them at feasible prices

More about Hinge Type Chip Conveyor System : Standard designs are available in a variety of sizes and configurations to meet your application and include plain, perforated, pimpled or pimpled & perforated aprons The material to be conveyed is brought to the required height at a defined incline and then discharged. There are more hinge belt systems in operation than any other kind. In most cases, therefore, turning machines are good candidates for hinge belt systems.



Working Principle : Transportation of the material takes place on the upper trough of a revolving hinged belt. Drivers ensure transport of the material up the inclined section. For wet machining the cooling lubrications are collected in the conveyor housing and can be fed back into a pump station.

Features :

  • Longer life and smoother performance with heavy-duty side frames
  • Interlocking belt side wings prevent jamming of material
  • Perfect for conveying a wide range of materials in demanding conditions
  • Custom engineered designs using standard components


Application : Our hinged belt conveyors can be used either as stand-alone conveyor at machine tools, large Conventional Machine Tools, CNC Machine Tools, middle / small Press and Laser Cutting Machines
